Dahua 46" Full HD Video Wall Display, 1.7mm Ultra-Narrow Bezel, 500 nits, 24/7 - DHI-LS460UDM-UF
46-inch Full HD LCD video wall unit with 1.7mm bezel-to-bezel seams, 500 nits, 24/7 industrial ADS panel, HDMI/DVI/VGA/DP inputs and DP loop-out for daisy chaining.
Read MoreSpecs
Brand
Dahua
Model
DHI-LS460UDM-UF
Product Type
LCD Video Wall Display Unit
Screen Size
46 inch (16:9)
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Dahua 46" Full HD Video Wall Display, 1.7mm Ultra-Narrow Bezel, 500 nits, 24/7 - DHI-LS460UDM-UF
The Dahua LS460UDM-UF is a 46-inch Full HD LCD display unit for building seamless video walls. It combines an industrial ADS panel rated for 24/7 operation, a 1.7mm bezel-to-bezel gap, 500 cd/m2 brightness, anti-glare surface and HDMI, DVI, VGA and DisplayPort inputs with DP loop-out. It suits surveillance control rooms, command centres, meeting rooms and commercial displays.
Main Specs
- 46" ADS panel, 1920 x 1080 Full HD, 16:9
- 1.7mm bezel-to-bezel (B2B) splicing gap
- Brightness 500 cd/m2, contrast 1200:1
- Rated for continuous 24/7 operation, MTBF 50,000 h
- Inputs: 2 x HDMI, 1 x DVI-D, 1 x VGA, 1 x DP; DP out for daisy chain
- Up to 4K@60Hz input on DP / HDMI 1
- Control: IR and RS-232 (in/out)
- Built-in power supply, 120W typical
- VESA 600 x 400 mm; wall or floor-stand mounting
- Ideal for control rooms and command centres building a video wall
Main Characteristics
Brand
Dahua
Model
DHI-LS460UDM-UF
Product Type
LCD Video Wall Display Unit
Screen Size
46 inch (16:9)
Panel Type
ADS
Resolution
1920 x 1080 (Full HD)
Bezel Width
B2B 1.7 mm (panel bezel to panel bezel); A2A 2.45 mm
Backlight
Direct LED
Brightness
500 cd/m2
Contrast Ratio
1200:1
Viewing Angle
178Β° (H) / 178Β° (V)
Response Time
8ms (G-to-G)
Color Depth
8-bit (16.7M)
Surface Treatment
Anti-glare, haze 25%, 3H
MTBF
50,000 hours
Inputs
VGA x1, DVI-D x1, HDMI x2, DP x1, RS232 x1, Audio x1, IR x1
Outputs
DP x1, RS232 x1, Audio x1
Control
Infrared, RS232
Power Supply
100-240 VAC, 50/60 Hz (built-in)
Power Consumption
120W typical, 140W max
VESA Mount
600 x 400 mm, M6
Installation
Floor-standing, wall-mounted
Dimensions
1021.2 x 575.8 x 122.7 mm (W x H x D)
Weight
17.9 kg
Operating Temperature
0 Β°C to 50 Β°C
