Dahua 4MP Smart Dual Light Vandal-Proof Dome IP Camera, 2.8mm, 30m, IK10, PoE - DH-IPC-HDBW2449FP-AS-IL-0280B
4MP WizSense dome IP camera with a 2.8 mm lens, Smart Dual Light up to 30 m, IVS, SMD Plus, built-in mic, audio and alarm ports, PoE and IP67/IK10.
Read MoreSpecs
Brand
Dahua
Model
DH-IPC-HDBW2449FP-AS-IL-0280B
Product Type
IP Dome Camera
Series
WizSense 2
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Dahua 4MP Smart Dual Light Vandal-Proof Dome IP Camera, 2.8mm, 30m, IK10, PoE - DH-IPC-HDBW2449FP-AS-IL-0280B
The Dahua IPC-HDBW2449F-AS-IL is a 4MP WizSense 2 vandal-proof dome network camera with Smart Dual Light. It combines a 1/2.7" 4MP sensor, a 2.8 mm lens, IR and warm light up to 30 m, IVS and SMD Plus detection, a built-in mic plus audio and alarm ports in an IP67/IK10 housing. It suits shops, schools and offices that want a tamper-resistant camera with alarm connections.
Main Specs
- 4MP resolution (2688 × 1520), 1/2.9" CMOS sensor
- Fixed-focal 2.8 mm lens, 101° horizontal view
- Smart Dual Light: Up to 30 m (IR) Up to 30 m (Warm light)
- H.265 / H.264 with Smart H.265+ / H.264+ to save bandwidth and storage
- Smart detection: Intrusion, tripwire (vehicle/human classification); SMD Plus
- Built-in microphone, audio input, audio output
- MicroSD card slot, up to 256 GB
- Power: 12 VDC/PoE (802.3af)
- IP67 / IK10 protection, metal housing
- Ideal for tamper-resistant coverage with alarm and audio connections
Main Characteristics
Brand
Dahua
Model
DH-IPC-HDBW2449FP-AS-IL-0280B
Product Type
IP Dome Camera
Series
WizSense 2
Resolution
4MP, 2688 × 1520
Image Sensor
1/2.9" CMOS
Lens
Fixed-focal, 2.8 mm
Field of View
H: 101°; V: 54°; D: 120°
Aperture
F1.6
Illumination Range
Up to 30 m (IR) Up to 30 m (Warm light)
Min. Illumination
0.006 lux@F1.6 (Color, 30 IRE); 0.0006 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
WDR
120 dB
Compression
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream); Smart H.265+; Smart H.264+
Smart Features
IVS: Intrusion, tripwire (vehicle/human classification); SMD Plus
Audio
built-in mic; audio in: 1 channel (RCA port); audio out: 1 channel (RCA port)
Storage
FTP; SFTP; Micro SD card (support max. 256 GB)
Network
RJ-45 (10/100 Base-T)
Power/PoE
12 VDC/PoE (802.3af)
Power Consumption
Basic: 2.3 W (12 VDC), 2.8 W (PoE); Max.: 7.1 W (12 VDC), 8.5 W (PoE) (H.265 + intelligence on+ WDR + illuminator intensity)
Protection
IP67; IK10
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Housing
Metal
Dimensions
55.0 mm × Φ108.9 mm
Weight
0.41 kg
