Dahua 64-Channel WizSense AI NVR, Up to 32MP, 8K HDMI, 8 SATA, RAID - DHI-NVR5864-EI2
64-channel WizSense NVR for IP cameras up to 32MP, 2 HDMI (up to 8K) + 2 VGA output, 8 SATA bays up to 26TB each, AI by recorder and Smart H.265+.
Read MoreSpecs
Brand
Dahua
Model
DHI-NVR5864-EI2
Product Type
Network Video Recorder (NVR)
Series
WizSense
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Dahua 64-Channel WizSense AI NVR, Up to 32MP, 8K HDMI, 8 SATA, RAID - DHI-NVR5864-EI2
The Dahua NVR5864-EI2 is a 64-channel WizSense series AI network video recorder in a 2U case. It combines 448 Mbps incoming bandwidth, IP cameras up to 32MP, 8K HDMI and VGA output and 8 SATA bays of up to 26TB each, plus RAID 0/1/5/6/10. It suits large sites such as factories, malls and multi-building projects that want smart search and fewer false alarms.
Main Specs
- 64 IP channels, cameras up to 32MP
- Bandwidth: 448 Mbps incoming / 448 Mbps recording / 448 Mbps outgoing
- Decoding: up to 40 x 1080p@30 fps
- Video output: 2 x HDMI (up to 8K 7680 x 4320) + 2 x VGA
- Storage: 8 SATA bays, up to 26TB per HDD, RAID 0/1/5/6/10
- AI by recorder: 4-ch Face Detection and Recognition, 16-ch SMD, 8-ch Perimeter Protection, 4-ch Video Metadata, 4-ch AcuPick
- Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG
- Network: 2 x RJ-45 (10/100/1000 Mbps); USB: 2 front USB 2.0 port, 2 rear USB 3.0 port
- N+M Cluster, iSCSI, RAID 0/1/5/6/10
- Ideal for large projects with up to 64 IP cameras
Main Characteristics
Brand
Dahua
Model
DHI-NVR5864-EI2
Product Type
Network Video Recorder (NVR)
Series
WizSense
Channels
64 IP channels
Max Camera Resolution
32MP
Network Bandwidth
AI disabled: 448 Mbps incoming, 448 Mbps recording and 448 Mbps outgoing; AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
Decoding Capability
40 Γ 1080p@30 fps
Video Output
2 x HDMI (up to 7680 x 4320 on the best port), 2 x VGA (up to 1920 x 1080)
Multi-screen Display
Main Screen: 1/4/8/9/16/25/36/64; Sub Screen: 1/4/8/9/16
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression
G.711a; G.711u; PCM; G726
AI by Recorder
4-ch Face Detection and Recognition, 16-ch SMD, 8-ch Perimeter Protection, 4-ch Video Metadata, 4-ch AcuPick
AI by Camera
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection; AcuPick
HDD Interface
8 SATA ports, each disk can contain up to 26 TB.;
RAID
RAID 0/1/5/6/10
Network Port
2 (10/100/1000 Mbps Ethernet port, RJ-45)
USB
4 (2 front USB 2.0 port, 2 rear USB 3.0 port)
Audio Input
1-channel RCA
Audio Output
2-channel RCA
Alarm Input
16 channels
Alarm Output
8 channels (1-channel 12 V 1 A outputοΌ
eSATA
1
RS-232
1
RS-485
1
Interoperability
ONVIF 25.12 (Profile T; Profile S; Profile G; Profile M); CGI; SDK
Mobile Access
iOS; Android
Power Supply
100β240 VAC, 50/60 Hz
Power Consumption
Total output of NVR is β€ 13 W (without HDD)
Dimensions
440.0 mm Γ 458.4 mm Γ 94.9 mm (W x D x H)
Weight
6.27 kg
Operating Temperature
β10 Β°C to +55 Β°C
