Dahua 8-Channel Lite 4K NVR, Up to 12MP, 4K HDMI, 1 SATA, 8 PoE Ports - DHI-NVR4108HS-8P-4KS3
8-channel Lite NVR for IP cameras up to 12MP, 4K HDMI + VGA output, 1 SATA bay up to 20TB, 8 PoE ports (72W) and Smart H.265+.
Read MoreSpecs
Brand
Dahua
Model
DHI-NVR4108HS-8P-4KS3
Product Type
Network Video Recorder (NVR)
Series
Lite
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Dahua 8-Channel Lite 4K NVR, Up to 12MP, 4K HDMI, 1 SATA, 8 PoE Ports - DHI-NVR4108HS-8P-4KS3
The Dahua NVR4108HS-8P-4KS3 is an 8-channel Lite series network video recorder in a Compact 1U case. It combines 160 Mbps incoming bandwidth, IP cameras up to 12MP, 4K HDMI and VGA output and one SATA bay of up to 20TB, with 8 built-in PoE ports to power the cameras. It suits homes, shops and small offices that want reliable, easy recording.
Main Specs
- 8 IP channels, cameras up to 12MP
- Bandwidth: 160 Mbps incoming / 160 Mbps recording / 80 Mbps outgoing
- Decoding: up to 8 x 1080p@30 fps
- Video output: 1 x HDMI (up to 4K 3840 x 2160) + 1 x VGA
- Storage: 1 SATA bay, up to 20TB per HDD
- PoE: 8 ports (IEEE 802.3 af/at), 72W total
- AI by recorder: 4-ch SMD
- Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264
- Network: 1 x RJ-45 (10/100/1000 Mbps); USB: 1 front USB 2.0 port, 1 rear USB 2.0 port
- Ideal for homes and small businesses that need an 8-camera IP system with PoE
Main Characteristics
Brand
Dahua
Model
DHI-NVR4108HS-8P-4KS3
Product Type
Network Video Recorder (NVR)
Series
Lite
Channels
8 IP channels
Max Camera Resolution
12MP
Network Bandwidth
AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing; AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Decoding Capability
8 Γ 1080p@30 fps
Video Output
1 x HDMI (up to 3840 x 2160), 1 x VGA (up to 1920 x 1080)
Multi-screen Display
Main Screen: 1/4/8/9; Sub Screen: 1/4/8/9
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264
Audio Compression
G.711a; G.711u; PCM; G726
AI by Recorder
4-ch SMD
AI by Camera
Face detection; face recognition; perimeter protection; SMD; people counting; stereo analysis; heat map
HDD Interface
1 SATA port. Each disk can contain up to 20 TB.
PoE Ports
8 ports, 10/100 Mbps, IEEE 802.3 af/at
PoE Budget
72 W total, max 25.5 W per port
Network Port
1 (10/100/1000 Mbps Ethernet port, RJ-45)
USB
2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
Audio Input
1-channel RCA
Audio Output
1-channel RCA
Interoperability
ONVIF 24.12 (Profile T; Profile S; Profile G); CGI; SDK
Mobile Access
iOS; Android
Power Supply
53 VDC, 1.81 A
Power Consumption
Total output of NVR is <10 W(without HDD); Total output power of PoE is 72 W, the maximum output power of a single port is 25.5 W
Dimensions
260.0 mm Γ 232.5 mm Γ 47.6 mm (W x D x H)
Weight
0.92 kg
Operating Temperature
β10 Β°C to +55 Β°C
