Dahua 8-Channel Lite NVR, Up to 8MP, 1080p HDMI, 1 SATA, 8 PoE Ports - DHI-NVR1108HS-8P-S3/H
8-channel Lite NVR for IP cameras up to 8MP, 1080p HDMI + VGA output, 1 SATA bay up to 8TB, 8 PoE ports (72W) and Smart H.265+.
Read MoreSpecs
Brand
Dahua
Model
DHI-NVR1108HS-8P-S3/H
Product Type
Network Video Recorder (NVR)
Series
Lite
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Dahua 8-Channel Lite NVR, Up to 8MP, 1080p HDMI, 1 SATA, 8 PoE Ports - DHI-NVR1108HS-8P-S3/H
The Dahua NVR1108HS-8P-S3/H is an 8-channel Lite series network video recorder in a Compact 1U case. It combines 80 Mbps incoming bandwidth, IP cameras up to 8MP, 1080p HDMI and VGA output and one SATA bay of up to 8TB, with 8 built-in PoE ports to power the cameras. It suits homes, shops and small offices that want reliable, easy recording.
Main Specs
- 8 IP channels, cameras up to 8MP
- Bandwidth: 80 Mbps incoming / 80 Mbps recording / 60 Mbps outgoing
- Decoding: up to 4 x 1080p@30 fps
- Video output: 1 x HDMI (up to 1080p) + 1 x VGA
- Storage: 1 SATA bay, up to 8TB per HDD
- PoE: 8 ports, 72W total
- Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264
- Network: 1 RJ-45 Port (10/100Mbps); USB: 1 front USB 2.0 port, 1 rear USB 2.0 port
- Ideal for homes and small businesses that need an 8-camera IP system with PoE
Main Characteristics
Brand
Dahua
Model
DHI-NVR1108HS-8P-S3/H
Product Type
Network Video Recorder (NVR)
Series
Lite
Channels
8 IP channels
Max Camera Resolution
8MP
Network Bandwidth
80 Mbps access, 80 Mbps storage and 60 Mbps for forwarding
Decoding Capability
4 Γ 1080p@30 fps
Video Output
1 x HDMI (up to 1920 x 1080), 1 x VGA (up to 1920 x 1080)
Multi-screen Display
1/4/8/9 views
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264
Audio Compression
PCM; G711A; G711U; G726
HDD Interface
1 SATA 2.0 port, up to 8TB for single HDD.
PoE Ports
8 ports, 10/100 Mbps
PoE Budget
72 W total, max 25.5W per port
Network Port
1 RJ-45 Port (10/100Mbps)
USB
1 front USB 2.0 port, 1 rear USB 2.0 port
Audio Input
1
Audio Output
1
Interoperability
ONVIF (profile T/S/G); CGI; SDK
Mobile Access
Android; iOS
Power Consumption
Total output of NVR is β€ 10 W (without HDD) (without HDD),Total Power of PoE is 72 W,the maximum output power of a single port is 25.5W
Dimensions
260 mm Γ 232.4 mm Γ 47.6 mm (W x D x H)
Weight
0.84 kg
Operating Temperature
β10 Β°C to 45 Β°C
