Dahua CS4006-4ET2GT-36 6-Port Cloud Managed Desktop Switch with 4-Port PoE (36W)
6-port 10/100 Mbps cloud-managed switch with 4 PoE ports (36W budget), Gigabit uplinks, 250 m long-distance PoE, ideal for IP cameras and access points.
Read MoreSpecs
Brand
Dahua
Model
CS4006-4ET2GT-36
Product Type
Cloud Managed PoE Switch
Layer
Layer 2
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Dahua CS4006-4ET2GT-36 6-Port Cloud Managed Desktop Switch with 4-Port PoE (36W)
The Dahua CS4006-4ET2GT-36 is a 6-port cloud managed desktop switch with 4-port PoE built for surveillance and small business networks. It combines 4 x RJ-45 10/100 Mbps (PoE), 2 x RJ-45 10/100/1000 Mbps (uplink) with a 36W PoE budget (IEEE802.3af, IEEE802.3at), 250 m long-distance PoE mode, web and DoLynk cloud management. It suits installers and offices that want to power IP cameras, access points or phones directly from the switch.
Main Specs
- 4 x RJ-45 10/100 Mbps (PoE)
- 2 x RJ-45 10/100/1000 Mbps (uplink)
- PoE: ports 1-4 up to 30 W, total up to 36 W
- PoE standards: IEEE802.3af, IEEE802.3at
- Switching capacity: 4.8 Gbps
- Management: web + DoLynk cloud (Layer 2)
- Long-distance PoE up to 250 m
- Power: external power adapter; desktop mount; wall mount
- Operating temperature: –10 °C to +55 °C
- Ideal for small camera kits that need 4 PoE ports and 36W of power
Main Characteristics
Brand
Dahua
Model
CS4006-4ET2GT-36
Product Type
Cloud Managed PoE Switch
Layer
Layer 2
Ports
Port 1-4: 4 × RJ-45 10/100 Mbps (PoE); Port 5-6: 2 × RJ-45 10/100/1000 Mbps (uplink)
Switching Capacity
4.8 Gbps
Packet Forwarding Rate
3.57 Mpps
PoE Power
Port 1-4 ≤ 30 W, total ≤ 36 W
PoE Standards
IEEE802.3af; IEEE802.3at
Long Distance PoE
Yes, up to 250 m
Packet Buffer
4 Mbit
MAC Table
2K
Jumbo Frame
9216 Byte
VLAN
IEEE 802.1Q VLAN
Management
Web Management; Cloud Management; Logs; Fault Alarm
Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az
Power Supply
External power supply: 53 VDC, 0.8 A
Power Consumption
Idling: ≤3 W; Full load: 42.4 W
Surge Protection
Common mode: 6 kV
Dimensions
115 mm × 84 mm × 27 mm (L x W x H)
Weight
0.2 kg
Installation
Desktop mount; wall mount
Operating Temperature
–10 °C to +55 °C
Casing
Sheet metal
