Dahua PFM920I Cat6 U/UTP Network Cable, Pure Copper 24AWG, CPR Eca
Dahua PFM920I Cat6 U/UTP cable with oxygen-free copper 24AWG conductors, PVC sheath and CPR Eca rating, in 305 m and 100 m boxes for PoE and network runs.
Read MoreSpecs
Brand
Dahua
Model
PFM920I-6UN-CN / PFM920I-6UN-C-100
Product Type
Cat6 U/UTP network cable
Conductor Material
Oxygen-free copper (99.97% purity)
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Dahua PFM920I Cat6 U/UTP Network Cable, Pure Copper 24AWG, CPR Eca
The Dahua PFM920I is a Cat6 U/UTP installation cable with solid oxygen-free copper conductors for network and PoE camera runs. It combines 0.53 mm (24AWG) 99.97% copper conductors, a cross separator, a PVC sheath with CPR Eca flame class and 250 MHz Cat6 performance. It suits installers cabling IP cameras, access points and office networks who want pure copper rather than CCA.
Main Specs
- Category: Cat6 U/UTP, 4 twisted pairs
- Conductor: oxygen-free copper (99.97%), 0.53 mm, 24AWG
- Insulation: HDPE; PE cross separator and rip cord
- Sheath: PVC, CPR Eca flame retardant class (EN 50575)
- Impedance: 100 Ω ± 15 Ω; attenuation 34.8 dB/100 m @ 250 MHz
- Max DC resistance: 9.0 Ω/100 m (305 m box)
- Supports Power over Ethernet
- Operating temperature: -20 °C to +60 °C
- Boxes: 305 m (white or gray) or 100 m (white)
- Ideal for IP camera and network installations that need pure copper Cat6
Available Options
- 305m / White
- 305m / Gray
- 100m / White
Main Characteristics
Brand
Dahua
Model
PFM920I-6UN-CN / PFM920I-6UN-C-100
Product Type
Cat6 U/UTP network cable
Conductor Material
Oxygen-free copper (99.97% purity)
Conductor Diameter
0.53 mm (24AWG)
Insulation
HDPE, 0.95 mm diameter
Pairs
4 pairs (8 cores)
Separator
PE cross separator
Sheath Material
PVC
Sheath Diameter
5.8 mm (305 m) / 6.0 mm (100 m)
Characteristic Impedance
100 Ω ± 15 Ω
Max Attenuation
34.8 dB/100 m @ 250 MHz
NEXT
≥ 39.3 dB/100 m @ 250 MHz
Return Loss
≥ 17.3 dB/100 m @ 250 MHz
Max DC Resistance
9.0 Ω/100 m (305 m) / 8.7 Ω/100 m (100 m)
Bending Radius
> 8 x cable diameter
Operating Temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Fire Rating
CPR Eca (EN 50575), IEC 60332-1-2
Length
305 m ± 2 m or 100 m ± 1 m per box
Net Weight
11.0 kg (305 m) / 3.8 kg (100 m)
Color
White, Gray (305 m); White (100 m)
