Dahua VTO3311Q-WP IP & Wi-Fi Villa Door Station, 2MP, IC Card, PoE, IP65 / IK08
Dahua VTO3311Q-WP metal IP and Wi-Fi villa door station with 2 MP 125° camera, IR, 120 dB WDR, IC card unlock, customisable buttons, PoE, IP65 / IK08.
Read MoreSpecs
Brand
Dahua
Model
DHI-VTO3311Q-WP
Product Type
IP & Wi-Fi villa door station
Camera
1/2.8" 2 MP CMOS
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Dahua VTO3311Q-WP IP & Wi-Fi Villa Door Station, 2MP, IC Card, PoE, IP65 / IK08
The Dahua VTO3311Q-WP is a full-metal villa door station that connects by network cable or Wi-Fi. It combines a 2 MP 125° camera with IR and 120 dB WDR, IC card unlock with local card issuing, customisable call buttons and PoE or 12 V power in an IP65 / IK08 housing. It suits villas, clinics and small offices that want card entry and video calls at the gate.
Main Specs
- 2 MP 1/2.8" CMOS, 125° horizontal field of view
- IR illumination, 120 dB WDR, 3D / 2D noise reduction
- Wi-Fi 2.4 GHz and RJ-45 10/100
- Unlock by IC card (0-3.5 cm), app or indoor monitor
- Customisable number of call buttons
- Ports: lock, exit button, door sensor, alarm in / out, RS-485
- Power: standard PoE or 12 V DC 1 A
- IP65 and IK08, aluminum alloy, -40 °C to +60 °C
- microSD up to 256 GB; 188.1 x 107.2 x 30 mm, grey
- Ideal for gates that need card entry and video calls
Main Characteristics
Brand
Dahua
Model
DHI-VTO3311Q-WP
Product Type
IP & Wi-Fi villa door station
Camera
1/2.8" 2 MP CMOS
Field of View
H 125°, V 65°, D 139°
WDR
120 dB
Night Vision
Auto IR
Video Compression
H.264, H.265
Audio
Two-way, echo suppression, noise reduction
Unlock Mode
IC card, app, indoor monitor
Card Reading Distance
0-3.5 cm
Network
RJ-45 10/100 Mbps, Wi-Fi 802.11b/g/n 2.4 GHz
Ports
RS-485, alarm in, alarm out, power out, exit button, door status, lock control
Storage
microSD up to 256 GB
Power Supply
12 V DC 1 A, standard PoE
Power Consumption
≤ 6 W working
Casing
Aluminum alloy, grey
Protection
IP65, IK08
Dimensions
188.1 x 107.2 x 30 mm
Net Weight
0.55 kg
Installation
Surface mount
Operating Temperature
-40 °C to +60 °C
Certifications
CE, FCC
