Ubiquiti UniFi Cloud Gateway Ultra - Compact Router with UniFi Network
Compact cloud gateway that runs UniFi Network for 30+ devices and 300+ clients
Read MoreSpecs
Brand
Ubiquiti
Model
UCG-ULTRA
Product
Cloud Gateway Ultra
Dimensions
141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
- Regular price
- $170.00 USD
- Sale price
- $170.00 USD
- Regular price
-
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Ubiquiti UniFi Cloud Gateway Ultra - Compact Router with UniFi Network
The Ubiquiti UniFi Cloud Gateway Ultra (UCG-ULTRA) is a compact cloud gateway that runs UniFi Network for 30+ devices and 300+ clients. It routes your internet with 1 Gbps IDS/IPS security and multi-WAN load balancing. It is small enough for a desk or shelf and needs no licence fees.
Main Specs
- Dimensions: 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
- Managed UniFi Devices: 30+
- Simultaneous Users Connected: 300+
- Max. WAN Port Count: 4
- Default WAN Ports: (1) 2.5 GbE RJ45
- 1 GbE RJ45: 4 (1G/100M/10M)
- 2.5 GbE RJ45: 1 (2.5G/1G/100M/10M)
- Max. Power Consumption: 6.2W
- Power Method: USB type C (5V DC/3A)
- Managed with the UniFi Network app, no licence fees
- Ideal for homes and small offices running UniFi
Main Characteristics
Brand
Ubiquiti
Model
UCG-ULTRA
Product
Cloud Gateway Ultra
Dimensions
141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Managed UniFi Devices
30+
Simultaneous Users Connected
300+
Max. WAN Port Count
4
Default WAN Ports
(1) 2.5 GbE RJ45
1 GbE RJ45
4 (1G/100M/10M)
2.5 GbE RJ45
1 (2.5G/1G/100M/10M)
IDS/IPS Throughput
1 Gbps
Form Factor
Compact desktop
IDS/IPS Signatures
55,000+ with CyberSecure
MAC Address Table Size
2,000
Max. Power Consumption
6.2W
Power Method
USB type C (5V DC/3A)
Power Supply
USB type C (5V DC/3A) (Adapter included)
Supported Voltage Range
100–240V AC
Heat Dissipation
21 BTU/hr
Processor
Quad-core ARM® Cortex®-A53 at 1.5 GHz
System Memory
3 GB
On-board Storage
16 GB
Weight
520 g (1.1 lb)
Enclosure Material
Polycarbonate
LCM Display
0.96" status display
Management
Ethernet Bluetooth
Button
(1) Factory reset
Ambient Operating Temperature
-10 to 40° C (14 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC, Anatel: 04653-24-08356, SRRC
