Ubiquiti UniFi Switch Pro Max 48 PoE - 48-Port 2.5GbE Layer 3 Etherlighting Switch, 720W
Layer 3 Etherlighting switch with 32 GbE and 16 2.5 GbE PoE+/PoE++ ports, 4 10G SFP+ uplinks, 720W PoE budget, 1U rack mount and RPS backup.
Read MoreSpecs
Brand
Ubiquiti
Model
USW-Pro-Max-48-PoE
Product Type
Managed Network Switch
1 GbE RJ45 Ports
32 (24 PoE+; 8 PoE++) (1G/100M/10M)
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Ubiquiti UniFi Switch Pro Max 48 PoE - 48-Port 2.5GbE Layer 3 Etherlighting Switch, 720W
The Ubiquiti UniFi Switch Pro Max 48 PoE is a 48-port Layer 3 Etherlighting switch with a mix of Gigabit and 2.5 GbE PoE ports. It provides 32 GbE and 16 2.5 GbE ports, all powered with PoE+ or PoE++, four 10G SFP+ uplinks and a 720W PoE budget in a 1U rack chassis. It suits large offices, schools and hotels with many access points, cameras and phones to power.
Main Specs
- (32) GbE RJ45 ports (24 PoE+, 8 PoE++)
- (16) 2.5 GbE RJ45 ports (8 PoE+, 8 PoE++)
- (4) 10G SFP+ uplink ports
- 720W total PoE availability, up to 64W per port
- Layer 3 switching with Etherlighting port LEDs
- 224 Gbps switching capacity
- 1U rack mount, 1.3" touchscreen, DC backup with UniFi RPS
- Managed with the UniFi Network app
- Ideal for large offices, schools and hotels with many PoE devices
Main Characteristics
Brand
Ubiquiti
Model
USW-Pro-Max-48-PoE
Product Type
Managed Network Switch
1 GbE RJ45 Ports
32 (24 PoE+; 8 PoE++) (1G/100M/10M)
2.5 GbE RJ45 Ports
16 (8 PoE+; 8 PoE++) (2.5G/1G/100M/10M)
10G SFP+ Ports
4 (10G/1G)
Max. PoE Output
Up to PoE++
Total PoE Availability
720W
Max. PoE per Port
PoE 15.4W, PoE+ 32W, PoE++ 64W
Layer 3
Yes
Etherlighting
Yes
Switching Capacity
224 Gbps
Non-Blocking Throughput
112 Gbps
Redundancy
DC Power Backup, with UniFi RPS
Power Supply
AC/DC, internal, 870W
Max. Power Consumption
100W (Excluding PoE Output), 820W (Including PoE Output)
Form Factor
Rack mount (1U)
Display
1.3" touchscreen
Dimensions
442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7")
Weight
Without mounting brackets: 6.2 kg (13.7 lb), With mounting brackets: 6.3 kg (13.9 lb)
Operating Temperature
-5 to 40Β° C (23 to 104Β° F)
