Ubiquiti UniFi Switch Pro XG 24 PoE - 24-Port 10G / 2.5G PoE+++ Layer 3 Switch
Layer 3 Etherlighting switch with 16 10 GbE and 8 2.5 GbE PoE+++ ports, 2 25G SFP28 uplinks, 720W PoE budget, 1U rack mount and RPS backup.
Read MoreSpecs
Brand
Ubiquiti
Model
USW-Pro-XG-24-PoE
Product Type
Managed Network Switch
10 GbE RJ45 Ports
16 (All PoE+++) (10G/5G/2.5G/1G/100M/10M), 10/100M half-duplex not supported
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3β5 Business Days)
15
Standard delivery with in-store pickup, 3β5 business days.
Express 1β2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1β2 business days.
Ubiquiti UniFi Switch Pro XG 24 PoE - 24-Port 10G / 2.5G PoE+++ Layer 3 Switch
The Ubiquiti UniFi Switch Pro XG 24 PoE is a professional 24-port Layer 3 Etherlighting switch built for multi-gig PoE. It offers 16 10 GbE and eight 2.5 GbE ports, all PoE+++ up to 90W, plus two 25G SFP28 uplinks and a 720W PoE budget in a 1U rack chassis. It suits enterprises deploying high-end WiFi 7 access points and other power-hungry multi-gig devices.
Main Specs
- (16) 10 GbE RJ45 ports, all PoE+++
- (8) 2.5 GbE RJ45 ports, all PoE+++
- (2) 25G SFP28 uplink ports
- 720W total PoE, up to 90W per port (802.3bt Type 4)
- Layer 3 switching with Etherlighting port LEDs
- 460 Gbps switching capacity
- 1U rack mount, 1.3" touchscreen, DC backup with UniFi RPS
- Managed with the UniFi Network app
- Ideal for enterprises deploying high-end WiFi 7 access points
Main Characteristics
Brand
Ubiquiti
Model
USW-Pro-XG-24-PoE
Product Type
Managed Network Switch
10 GbE RJ45 Ports
16 (All PoE+++) (10G/5G/2.5G/1G/100M/10M), 10/100M half-duplex not supported
2.5 GbE RJ45 Ports
8 (All PoE+++) (2.5G/1G/100M/10M), 10/100M half-duplex not supported
25G SFP28 Ports
2 (25G/10G/1G)
Max. PoE Output
Up to PoE+++, 802.3bt Type 4, Class 8
Total PoE Availability
720W
Max. PoE per Port
PoE 15.4W, PoE+ 30W, PoE++ 60W, PoE+++ 90W
Layer 3
Yes
Etherlighting
Yes
Switching Capacity
460 Gbps
Non-Blocking Throughput
230 Gbps
Redundancy
DC Power Backup, with UniFi RPS
Power Supply
AC/DC, internal, 870W
Max. Power Consumption
150W (Excluding PoE Output), 870W (Including PoE Output)
Form Factor
Rack mount (1U)
Display
1.3" touchscreen
Dimensions
442 x 480 x 44 mm (17.4 x 18.9 x 1.7")
Weight
Without mounting brackets: 7.9 kg (17.4 lb), With mounting brackets: 8 kg (17.6 lb)
Operating Temperature
-5 to 40Β° C (23 to 104Β° F)
