Ubiquiti UniFi U6+ WiFi 6 Ceiling Access Point
Compact ceiling-mounted dual-band WiFi 6 access point with 4 spatial streams
Read MoreSpecs
Brand
Ubiquiti
Model
U6-PLUS
Product
Access Point U6 Plus
Dimensions
⌀160 x 33 mm (⌀6.3 x 1.3")
- Regular price
- $145.00 USD
- Sale price
- $145.00 USD
- Regular price
-
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Ubiquiti UniFi U6+ WiFi 6 Ceiling Access Point
The Ubiquiti UniFi U6 Plus (U6-PLUS) is a compact ceiling-mounted dual-band WiFi 6 access point with 4 spatial streams. It improves on the U6 Lite with higher performance and runs on standard PoE. It is managed with the free UniFi Network app with no licence fees.
Main Specs
- Dimensions: ⌀160 x 33 mm (⌀6.3 x 1.3")
- WiFi Standard: WiFi 6
- Spatial Streams: 4
- Coverage Area: 140 m² (1,500 ft²)
- Max. Client Count: 300+
- Uplink: GbE
- Mounting: Ceiling, Wall (Mounts Included)
- Max. Power Consumption: 9W
- Networking Interface: (1) GbE RJ45 port
- Managed with the UniFi Network app, no licence fees
- Ideal for homes, offices and small businesses
Main Characteristics
Brand
Ubiquiti
Model
U6-PLUS
Product
Access Point U6 Plus
Dimensions
⌀160 x 33 mm (⌀6.3 x 1.3")
WiFi Standard
WiFi 6
Spatial Streams
4
Coverage Area
140 m² (1,500 ft²)
Max. Client Count
300+
Uplink
GbE
Mounting
Ceiling, Wall (Mounts Included)
Power Method
PoE
5 GHz
23 dBm
2.4 GHz
23 dBm
Max. BSSIDs
8 per Radio
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
Max. Power Consumption
9W
Supported Voltage Range
44–57V DC
Networking Interface
(1) GbE RJ45 port
Weight
Device: 338 g (11.9 oz) With mount: 413 g (14.6 oz)
Management
Ethernet
Enclosure Material
Polycarbonate, aluminum
Mount Material
ABS, SGCC steel
System
White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
Operating Frequency
US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz, For worldwide, it depends on the regulatory region
Ambient Operating Temperature
-30 to 60° C (-22 to 140° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC, SRRC, Anatel: 10539-23-08356
