Ubiquiti UniFi U7 Lite WiFi 7 Ceiling Access Point - 2.5GbE
Compact ceiling-mounted WiFi 7 access point with 4 spatial streams
Read MoreSpecs
Brand
Ubiquiti
Model
U7-LITE
Product
Access Point U7 Lite
Dimensions
⌀171.5 x 33 mm (⌀6.8 x 1.3")
- Regular price
- $145.00 USD
- Sale price
- $145.00 USD
- Regular price
-
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Ubiquiti UniFi U7 Lite WiFi 7 Ceiling Access Point - 2.5GbE
The Ubiquiti UniFi U7 Lite (U7-LITE) is a compact ceiling-mounted WiFi 7 access point with 4 spatial streams. It brings WiFi 7 to homes and small offices with a 2.5 GbE uplink and PoE power. It is managed with the free UniFi Network app with no licence fees.
Main Specs
- Dimensions: ⌀171.5 x 33 mm (⌀6.8 x 1.3")
- WiFi Standard: WiFi 7
- Spatial Streams: 4
- Coverage Area: 115 m² (1,250 ft²)
- Max. Client Count: 200+
- Uplink: 2.5 GbE
- Mounting: Ceiling, Wall (Lite Mount Included)
- Max. Power Consumption: 13W
- Networking Interface: (1) 2.5 GbE RJ45 port
- Managed with the UniFi Network app, no licence fees
- Ideal for homes, small offices and shops
Main Characteristics
Brand
Ubiquiti
Model
U7-LITE
Product
Access Point U7 Lite
Dimensions
⌀171.5 x 33 mm (⌀6.8 x 1.3")
WiFi Standard
WiFi 7
Spatial Streams
4
Coverage Area
115 m² (1,250 ft²)
Max. Client Count
200+
Uplink
2.5 GbE
Mounting
Ceiling, Wall (Lite Mount Included)
Power Method
PoE
5 GHz
24 dBm
2.4 GHz
23 dBm
Max. BSSIDs
8 per Radio
802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240), Depends on regulatory region
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
Max. Power Consumption
13W
Supported Voltage Range
42.5–57V DC
Networking Interface
(1) 2.5 GbE RJ45 port
Weight
313 g (11 oz)
Management
Ethernet
Enclosure Material
UV-stabilized polycarbonate
Mount Material
UV-stabilized polycarbonate, galvanized steel (SGCC)
System
White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
Ambient Operating Temperature
-30 to 40° C (-22 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC, SRRC, Anatel: 02143-25-08356
