Ubiquiti UniFi U7 Pro WiFi 7 Ceiling Access Point - 6 GHz, 2.5GbE
Ceiling-mounted WiFi 7 access point with 6 spatial streams and 6 GHz support
Read MoreSpecs
Brand
Ubiquiti
Model
U7-PRO
Product
Access Point U7 Pro
Dimensions
⌀206 x 46 mm (⌀8.1 x 1.8")
- Regular price
- $270.00 USD
- Sale price
- $270.00 USD
- Regular price
-
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Ubiquiti UniFi U7 Pro WiFi 7 Ceiling Access Point - 6 GHz, 2.5GbE
The Ubiquiti UniFi U7 Pro (U7-PRO) is a ceiling-mounted WiFi 7 access point with 6 spatial streams and 6 GHz support. It delivers fast, interference-free WiFi in busy spaces with a 2.5 GbE uplink and PoE+ power. It is managed with the free UniFi Network app with no licence fees.
Main Specs
- Dimensions: ⌀206 x 46 mm (⌀8.1 x 1.8")
- WiFi Standard: WiFi 7, With 6 GHz support
- Spatial Streams: 6
- Coverage Area: 140 m² (1,500 ft²)
- Max. Client Count: 300+
- Uplink: 2.5 GbE
- Mounting: Ceiling, Wall (Pro Mount Included)
- Max. Power Consumption: 21W
- Networking Interface: (1) 1/2.5 GbE RJ45 port
- Managed with the UniFi Network app, no licence fees
- Ideal for offices, hotels, schools and demanding homes
Main Characteristics
Brand
Ubiquiti
Model
U7-PRO
Product
Access Point U7 Pro
Dimensions
⌀206 x 46 mm (⌀8.1 x 1.8")
WiFi Standard
WiFi 7, With 6 GHz support
Spatial Streams
6
Coverage Area
140 m² (1,500 ft²)
Max. Client Count
300+
Uplink
2.5 GbE
Mounting
Ceiling, Wall (Pro Mount Included)
Power Method
PoE+
6 GHz
23 dBm
5 GHz
26 dBm
2.4 GHz
23 dBm
Max. BSSIDs
8 per Radio
802.11be (WiFi 7)
7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
802.11ax (WiFi 6/6E)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
Max. Power Consumption
21W
Supported Voltage Range
44–57V DC
Networking Interface
(1) 1/2.5 GbE RJ45 port
Weight
680 g (1.5 lb)
Management
Ethernet
Enclosure Material
Polycarbonate, metal
Mount Material
Stainless steel (SUS304), galvanized steel (SGCC)
System
White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
Operating Frequency
US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8: 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz 5925 - 7125 MHz, For worldwide, it depends on the regulatory region
Ambient Operating Temperature
-30 to 40° C (-22 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC, Anatel: 06370-24-08356
