Ubiquiti UniFi U7 Pro XGS WiFi 7 Ceiling Access Point - 6 GHz, 10GbE, White
Ceiling-mounted WiFi 7 access point with 8 spatial streams, 6 GHz support, a dedicated spectral scanning radio, 500+ clients and a 10/5/2.5/1 GbE PoE++ uplink.
Read MoreSpecs
Brand
Ubiquiti
Model
U7-Pro-XGS
Product Type
Ceiling WiFi 7 Access Point
WiFi Standard
WiFi 7, with 6 GHz support
Express Shipping
Shipping Info
Fast delivery options for your convenience
Pick-Up in Store
Free
Select this option to pick up your order directly from our store. Fast and convenient!
Standard (3–5 Business Days)
15
Standard delivery with in-store pickup, 3–5 business days.
Express 1–2 Business Days
from $25
For quick delivery, choose Express shipping, and get your order within 1–2 business days.
Ubiquiti UniFi U7 Pro XGS WiFi 7 Ceiling Access Point - 6 GHz, 10GbE, White
The Ubiquiti UniFi U7 Pro XGS is a ceiling-mounted WiFi 7 access point with 8 spatial streams, 6 GHz support and a dedicated spectral scanning radio. Its 10 GbE uplink, which also runs at 5, 2.5 or 1 GbE, removes the wired bottleneck for 500+ clients over about 160 m², powered by PoE++. It suits offices, hotels and venues building a multi-gig WiFi 7 network managed from the UniFi Network app.
Main Specs
- WiFi 7 with 6 GHz support, 8 spatial streams
- Up to 5.8 Gbps on 6 GHz, 8.6 Gbps on 5 GHz and 688 Mbps on 2.4 GHz
- Coverage up to 160 m² (1,750 ft²), 500+ clients
- (1) 10 GbE RJ45 uplink (10/5/2.5/1 GbE)
- PoE++ powered, 29W max. power consumption
- Dedicated spectral scanning radio and zero-wait DFS
- Ceiling or wall mounting (Lite Mount included), white
- Managed with the UniFi Network app, no licence fees
- Ideal for offices, hotels and venues building multi-gig WiFi 7 networks
Main Characteristics
Brand
Ubiquiti
Model
U7-Pro-XGS
Product Type
Ceiling WiFi 7 Access Point
WiFi Standard
WiFi 7, with 6 GHz support
Spatial Streams
8
MIMO 6 GHz
2 x 2 (DL/UL MU-MIMO)
MIMO 5 GHz
4 x 4 (DL/UL MU-MIMO)
MIMO 2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate 6 GHz
5.8 Gbps (BW320)
Max. Data Rate 5 GHz
8.6 Gbps (BW240)
Max. Data Rate 2.4 GHz
688 Mbps (BW40)
Coverage Area
160 m² (1,750 ft²)
Max. Client Count
500+
Uplink
10 GbE
Networking Interface
(1) 10 GbE RJ45 port
Power Method
PoE++
Max. Power Consumption
29W
Mounting
Ceiling, Wall (Lite Mount Included)
Dimensions
⌀215 x 32.5 mm (⌀8.5 x 1.3")
Weight
800 g (1.8 lb)
Color
White
Operating Temperature
-30 to 40° C (-22 to 104° F)
